Hertz MPS 250 S2 – Ultra-Shallow 10″ 2-Ohm Subwoofer for Harley Touring

The Hertz MPS 250 S2 is a premium ultra-shallow 10″ subwoofer engineered for riders who want big, controlled bass performance in the smallest possible space. With only 82.6 mm mounting depth, a 2-ohm voice coil, and 500 W RMS power handling, this is the ideal sub for Tour-Paks, saddlebag drop-in boxes, and compact sealed enclosures on Harley-Davidson® Touring bikes.

Who This Is For

  • Harley-Davidson Touring riders adding bass where mounting depth is the limit, such as Tour-Paks and saddlebag drop-in boxes.
  • Builds using a small sealed enclosure of 12–14 litres rather than a large box that eats your storage space.
  • Riders who want stronger low-end that supports the fairing and rear speakers without muddying vocals.
  • Systems running a mono amplifier able to deliver at least 300 W RMS, with 400–600 W RMS ideal.
  • Not a drop-in on its own: it needs a sealed enclosure, and high-power systems may require upgraded charging or secondary battery support.

Key Features

  • Ultra-shallow 82.6 mm design fits where traditional subs cannot.
  • 2-ohm single voice coil maximises power from modern motorcycle mono amps.
  • 500 W RMS / 1000 W peak for high-output bass performance.
  • High-excursion design delivers strong low-end in very small enclosures.
  • Optimised for sealed boxes commonly used in motorcycle applications.
  • Die-cast aluminium basket for strength in high-vibration environments.

Why It Works on Harleys

  • Fits tight spaces like Tour-Paks and saddlebag sub chambers.
  • 2-ohm design pairs perfectly with strong motorcycle mono amps (e.g., Hertz SP1.900).
  • Small sealed box performance gives real bass without sacrificing all your storage space.
  • Strong low-end extension supports fairing and rear speakers without muddying vocals.

Recommended Power & Setup

  • Amplifier Power: 400–600 W RMS ideal
  • Minimum: 300 W RMS
  • Enclosure Type: Sealed
  • Sealed Volume: 12–14 litres (0.42–0.49 cu ft). Hertz's published reference enclosure is sealed 14.2 litres (0.5 cu ft) with a system resonance (Fc) of 47.7 Hz and Qtc 0.68.
  • Low-Pass Filter: 80–120 Hz @ 12–24 dB/octave
  • Electrical Note: High-power systems may require upgraded charging or secondary battery support.

Fitment

  • Perfect for Harley-Davidson Touring subwoofer builds
  • Ideal in Tour-Pak sub boxes
  • Works with many shallow saddlebag drop-in sub enclosures
  • Suitable for custom sealed pods where depth is limited

Specifications

Subwoofer Size 10″
Impedance 2 Ω (Single Voice Coil)
RMS Power 500 W
Peak Power 1000 W
Sensitivity 82.5 dB SPL
Frequency Response 25–400 Hz
Resonant Frequency (Fs) 28 Hz
Xmax 16.8 mm
Mechanical Excursion (Xmech) 20 mm
Cone Material Polypropylene
Voice Coil 38 mm (1.5″), six-layer copper
Magnet High-density flux ferrite, 134 × 55 × 36 mm
Mounting Depth 82.6 mm (3.25″)
Overall Height 103.2 mm (4.06″)
Recommended Sealed Volume 12–14 L (0.42–0.49 cu ft)
Hertz Reference Enclosure Sealed 14.2 L (0.5 cu ft), Fc 47.7 Hz, Qtc 0.68
Weight 5.1 kg (11.27 lbs)
Grilles Included Yes – Hertz lists a screw-less mesh grille with black screws in the feature list. Please confirm pack contents with MAA if in doubt.
Re 2.2 Ω
Le 2.67 mH
Vas 24.5 L
Mms 250 g
Cms 0.13 mm/N
BL 14.7 T·m
Qts 0.41
Qms 5.3

Specifications per Hertz published technical documentation.

Need Box Design Advice?

The MPS 250 S2 performs best in small, well-sealed enclosures. We can help you choose or design the right Tour-Pak or saddlebag sub mounts to maximise output and maintain storage space.
