Cicada Audio CMB10.S4 — 10" High-Power Motorcycle Mid-Bass Driver (4Ω, 800W RMS)
Cicada Audio CMB10.S4 — 10" High-Power Motorcycle Mid-Bass Driver (4Ω, 800W RMS)
The Cicada Audio CMB10.S4 is a monster 10-inch mid-bass driver engineered for extreme-output Harley-Davidson audio builds.
With an enormous 800W RMS / 1600W MAX power rating and a heavy-duty 3-inch, 6-layer Black Coat™ voice coil, this mid-bass driver is built for riders who demand chest-punching impact, deep authority and uncompromising performance at highway speeds.
The vented Y30 ferrite motor, die-cast aluminium basket, and advanced thermal management make the CMB10.S4 ideal for high-power Class-D motorcycle amplifiers. Whether used in saddlebag lids, stretched bags or custom pods, it delivers serious mid-bass presence in any Harley touring system.
Key Features
- 800W RMS / 1600W MAX: Massive real-world mid-bass capability for high-output systems.
- 3" Black Coat™ voice coil: Six-layer, high-temp coil engineered for brutal power handling.
- Y30 ferrite motor: Produces deep, controlled, accurate mid-bass with authority.
- Advanced cooling system: Vented coil gap + heat-sink assembly for maximum thermal stability.
- Die-cast aluminium basket: Rigid, vibration-resistant construction ideal for motorcycles.
- Wide usable frequency range: 35 Hz – 3 kHz for deep impact and punch.
- High sensitivity (87.2 dB): Strong output with modern motorcycle amplifiers.
- Built for motorcycle environments: Engineered for heat, vibration and harsh riding conditions.
Specifications
| Cicada Audio CMB10.S4 – Technical Specifications | |
|---|---|
| GENERAL | |
| Driver Size | 10-inch |
| Impedance | 4Ω |
| Power Handling | 800W RMS / 1600W MAX |
| MOTOR & COIL | |
| Magnet | Y30 Ferrite Ceramic |
| Voice Coil | 3-inch / 6-layer Black Coat™ |
| Cooling | Vented coil gap + advanced heat-sink assembly |
| AUDIO PERFORMANCE | |
| Frequency Response | 35 Hz – 3 kHz ±5 dB |
| Sensitivity | 87.2 dB (1W/1M) |
| PHYSICAL | |
| Total Diameter | 10.24" / 260 mm |
| Mounting Diameter | 8.98" / 228 mm |
| Mounting Depth | 4.31" / 109.5 mm |
Motorcycle Fitment
- Designed for Harley-Davidson Touring saddlebag lids, stretched bags, side covers and custom 10" pods.
- Perfect for high-output Class-D amplifier systems.
- Built for riders chasing deep, authoritative mid-bass that keeps up with horn-loaded fronts.
Compatible Harley-Davidson Models (10" adaptor required)
- 2009–2013 — CVO Electra Glide
- 2009–2013, 2015–2023 — CVO Road Glide
- 1998–2023 — CVO Street Glide
- 1998–2023 — Electra Glide
- 2014–2025 — Electra Glide Police
- 2019–2022 — Electra Glide Standard
- 1998–2013, 2015–2023 — Road Glide
- 2024–2025 — Road Glide Police
- 2015–2023 — Road Glide Special
- 2015–2024 — Road Glide Ultra / Limited
- 1998–2023 — Street Glide
- 2014–2023 — Street Glide Special
- 2014–2019 — Ultra Classic
- 2014–2024 — Ultra Limited
Ideal For
- High-power Harley touring mid-bass systems
- Riders using 400–800W RMS amplifier channels
- Custom pods, stretched bags and SPL-style builds
Planning a big mid-bass Harley build?
Motorcycle Audio Australia can help match the CMB10.S4 with the right amplifier, DSP and enclosure solution.
