Cicada Audio FLX1600.1 — 1-Channel High-Power Class-D Motorcycle Subwoofer Amplifier (1,600W RMS @ 2Ω)
Cicada Audio FLX1600.1 — 1,600W Mono Class-D Amplifier for Motorcycle Subwoofers & Midbass
When your Harley needs real bass, the FLX1600.1 brings the thunder.
The Cicada Audio FLX1600.1 is a compact but insanely powerful mono Class-D amplifier engineered specifically for motorcycle subwoofers and high-output midbass systems. Delivering up to 1,600W RMS @ 2Ω and 950W RMS @ 4Ω, this amp is purpose-built to drive 8", 10" and 12" motorcycle subs or serious midbass drivers with clean, controlled authority.
Smaller than many 4-channel amps but capable of true subwoofer power, the FLX1600.1 fits easily into saddlebags, amp racks, and custom enclosures while handling the heat, vibration and voltage swings of real-world Harley-Davidson Touring platforms.
Key Features
- Massive real-world output: Up to 1,600W RMS @ 2Ω and 950W RMS @ 4Ω.
- Compact Class-D architecture: High efficiency and low heat — perfect for motorcycle enclosures.
- Motorcycle-ready durability: Engineered for heat, vibration and 9–16V operation.
- Advanced crossovers: HPF 10–80 Hz and LPF 80–20 kHz for precise sub and midbass tuning.
- High damping factor (200): Tight, controlled bass even at extreme listening levels.
- OEM-friendly turn-on: REM or DC auto turn-on works with Harley Boom!Box and aftermarket head units.
- System requirement: Requires 4 AWG power wire (HDPG4K) for safe and correct operation.
Specifications
| Cicada Audio FLX1600.1 — Technical Specifications | |
|---|---|
| OUTPUT POWER (RMS) | |
| 4Ω Mono @ 12.5V | 670W x1 |
| 4Ω Mono @ 14.4V | 950W x1 |
| 2Ω Mono @ 12.5V | 1,250W x1 |
| 2Ω Mono @ 14.4V | 1,600W x1 |
| AUDIO PERFORMANCE | |
| Frequency Response | 10 Hz – 20 kHz ±3 dB |
| THD | <0.5% |
| Damping Factor | 200 |
| SNR | 86 dB |
| CROSSOVER | |
| HPF | 10 – 80 Hz |
| LPF | 80 – 20,000 Hz |
| Slope | 12 dB/octave |
| INPUTS & ELECTRICAL | |
| Gain Range | 0.2 – 12 V AC |
| Operating Voltage | 9 – 16 V DC |
| Turn-On Mode | REM / DC auto turn-on |
| Total Efficiency | 80% |
| Current Draw (Music / Max) | 70 A / 140 A |
| Recommended Fuse | 100 A |
| Power Wiring Requirement | Requires 4 AWG power wire (HDPG4K) |
| PHYSICAL | |
| Dimensions (W × D × H) | 8.6 × 4.9 × 2.0 in (218 × 124 × 51 mm) |
Why It Works So Well on Motorcycles
- Perfect for bagger subs: Built to run 8–12" motorcycle subwoofers with real authority.
- Small enough to hide: Fits in saddlebags, side covers and amp trays.
- Stays strong at speed: Deep, controlled bass even at highway cruising.
- Engineered for Aussie conditions: Heat, vibration and long-distance riding are no issue.
Fitment
- Harley-Davidson Touring Models (1998–2024)
- Street Glide, Road Glide, Ultra, CVO and Tri Glide
- Installs in saddlebags, amp trays, side covers or custom sub enclosures
Recommended System Matching
- Pairs perfectly with Cicada motorcycle subwoofers and midbass drivers.
- Run at 2Ω for maximum rated output.
- Add a DSP for precise bass shaping and time alignment.
Building real bass into your Harley?
Motorcycle Audio Australia can design a full sub-stage around the FLX1600.1 to match your goals.
